Adaptive and secure frame-locking bicycle rack

Bicycle rack CubiQ Standard, 1-sided

See Similar Products

Flexible capacity with adjustable hoop spacing and angles for optimal use of space
Three mounting options available, made from hot-dip galvanised steel
Examples shown for configurations of 3–6 bikes. Contact our sales team for longer, continuous bike rack rows tailored to your needs

Read the product description and specifications See downloadable files

516,00 €

VAT 0% | Log in or create an account - Your reduced price will be displayed.

Choose model:

Bicycle rack CubiQ Standard, 1-sided

516,00 €

(VAT 0%)

Select Options

SKU: 1000312SPM

Delivery time

Over a million products installed

Deliveries all over the world

Finbin products are designed and manufactured in Finland

Accessories

Product description

CubiQ Standard Bicycle Rack — Secure and Adjustable Frame-Locking Bicycle Parking

The CubiQ Standard bike rack is designed to make frame locking easy and secure. This stylish, one-sided bike rack is available with surface-mounted, in-ground or wall-mounted installation.

The surface-mounted and in-ground bike rack is supplied with two sturdy posts. The examples below show configurations for 3–6 bikes with different hoop spacing options to suit your site. The overall length depends on the number of bike spaces and the spacing between the hoops. Contact our sales team for larger configurations and longer, continuous rows of bike racks.

Arch spacing	Bicycle spaces	Overall length
420 mm	4	1645 mm
500 mm	3	1645 mm
600 mm	3	1645 mm
420 mm	5	2055 mm
500 mm	4	2055 mm
420 mm	6	2470 mm
500 mm	5	2470 mm
600 mm	4	2470 mm

The supplied height- and width-adjustable mounting bracket enables flexible and precise positioning during installation.

Arch spacing can also be adjusted after installation. The wheel-supporting wedge is designed to avoid contact with spokes and forks, making the rack suitable for wide-tire mountain bikes and fat bikes. At the same time, it helps protect brake discs from bending and provides stable support for narrower commuter bike tires (28–35 mm).

The three-position arch angle adjustment allows each rack loop to be oriented left, center, or right, improving space efficiency and parking convenience.

CubiQ is manufactured from high-quality materials, featuring a zinc-primed and powder coated steel frame for long-lasting durability.

Build a bike rack row to suit your needs

Do you need a continuous row of bike racks or a larger configuration for more bikes? CubiQ is a fully modular bike rack system that can be combined and extended to suit your space and the number of bike parking spaces required. Contact us, and we’ll help design a configuration that meets your needs.

Technical specifications

Värit

Corten Finbin Black 1945 RAL 1015 - Light Ivory Textured DB703 Textured Grey RAL 9011 - Graphite Black RAL 9010 - Pure White RAL 9006 - White Aluminium RAL 9005 - Jet Black RAL 8024 - Beige Brown RAL 8019 - Grey Brown RAL 8003 - Clay Brown RAL 7024 - Graphite Grey RAL 7021 - Black Grey RAL 7012 - Basalt Grey RAL 7002 - Olive Grey RAL 6021 - Pale Green RAL 6018 - Yellow Green RAL 6012 - Black Green RAL 6005 - Moss Green RAL 5024 - Pastel Blue RAL 5002 - Ultramarine Blue RAL 3020 - Traffic Red RAL 3016 - Coral Red RAL 3012 - Beige Red RAL 2008 - Bright Red Orange RAL 1028 - Melon Yellow RAL 1019 - Grey Beige RAL 1013 - Oyster White RAL 1005 - Honey Yellow RAL 1002 - Sand Yellow
